Essentials

Product Collection

Intel® Xeon® CPU Max Series

Code Name

Products formerly Sapphire Rapids HBM

Vertical Segment

Server

Processor Number

9462

Lithography

Intel 7

Use Conditions

Server/Enterprise

Recommended Customer Price

CPU Specifications

Total Cores

32

Total Threads

64

Max Turbo Frequency

3.50 GHz

Processor Base Frequency

2.70 GHz

Cache

75 MB

Intel® UPI Speed

16 GT/s

Max # of UPI Links

3

TDP

350 W

Supplemental Information

Marketing Status

Launched

Launch Date

Q1'23

Embedded Options Available

No

Memory Specifications

Max Memory Size (dependent on memory type)

6 TB

Memory Types

DDR5-4800

Maximum Memory Speed

4800 MHz

Max # of Memory Channels

8

Maximum High Bandwidth Memory (HBM)†

64 GB

Expansion Options

Scalability

2S

PCI Express Revision

5.0

Max # of PCI Express Lanes

80

Package Specifications

Sockets Supported

FCLGA4677

Package Carrier

E1C

DTS Max

100 °C

TCASE

77°C

Package Size

100mm x 56.5mm

Advanced Technologies

Intel® Data Streaming Accelerator (DSA)

4 default devices

Intel® Advanced Matrix Extensions (AMX)

Yes

Intel® Speed Select Technology – Core Power

Yes

Intel® Deep Learning Boost (Intel® DL Boost)

Yes

Intel® Resource Director Technology (Intel® RDT)

Yes

Intel® Speed Shift Technology

Yes

Intel® Turbo Boost Technology ‡

2.0

Intel® Hyper-Threading Technology ‡

Yes

Intel® Transactional Synchronization Extensions

Yes

Intel® 64 ‡

Yes

Instruction Set Extensions

Intel® AMX |  Intel® SSE4.2 |  Intel® AVX |  Intel® AVX2 |  Intel® AVX-512

# of AVX-512 FMA Units

2

Security & Reliability

Intel® Crypto Acceleration

Yes

Intel® Platform Firmware Resilience Support

Yes

Intel® Control-Flow Enforcement Technology

Yes

Intel® Total Memory Encryption

Yes

Intel® AES New Instructions

Yes

Intel® Software Guard Extensions (Intel® SGX)

Yes with Intel® SPS

Maximum Enclave Page Cache (EPC) Size for Intel® SGX

128 GB

Intel® OS Guard

Yes

Intel® Trusted Execution Technology ‡

Yes

Execute Disable Bit ‡

Yes

Intel® Boot Guard

Yes

Intel® Run Sure Technology

Yes

Mode-based Execute Control (MBEC)

Yes

Intel® Virtualization Technology (VT-x) ‡

Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡

Yes

Intel® VT-x with Extended Page Tables (EPT) ‡

Yes
