| General information | |
| Type | CPU / Microprocessor |
| Market segment | Server |
| Family | Intel Xeon W-1300 series |
| Model number | W-1370 |
| CPU part numbers |
|
| Frequency | 2.9 GHz / 2900 MHz |
| Maximum turbo frequency | 5.1 GHz / 5100 MHz |
| Bus speed | 8 GT/s Direct Media Interface |
| Clock multiplier | 29 |
| Package | 1200-land Flip-Chip Land Grid Array |
| Socket | Socket 1200 |
| Size | 1.48" x 1.48" / 3.75cm x 3.75cm |
| Architecture / Microarchitecture | |
| Instruction set | x86 |
| Microarchitecture | Rocket Lake |
| Core stepping | B0 |
| Manufacturing process | 0.014 micron |
| Data width | 64 bit |
| The number of CPU cores | 8 |
| The number of threads | 16 |
| Floating Point Unit | Integrated |
| Level 1 cache size | 8 x 32 KB 8-way set associative instruction caches 8 x 48 KB 12-way set associative data caches |
| Level 2 cache size | 8 x 512 KB 8-way set associative caches |
| Level 3 cache size | 16 MB 16-way set associative inclusive shared cache |
| Physical memory | 128 GB |
| Multiprocessing | Uniprocessor |
| Extensions & Technologies |
|
| Security Features |
|
| Low power features | Enhanced SpeedStep technology |
| Integrated Graphics Processing Unit | |
| GPU Type | Intel UHD P750 |
| Microarchitecture | Intel Xe |
| Execution units | 32 |
| Base frequency (MHz) | 350 |
| Maximum frequency (MHz) | 1300 |
| Integrated peripherals / components | |
| Display controller |
|
| Memory controller | The number of controllers: 1 Memory channels (per controller): 2 Memory channels (total): 2 Supported memory: DDR4-3200 ECC supported: Yes |
| Other peripherals |
|
| Electrical / Thermal parameters | |
| Minimum/Maximum operating temperature | 0°C (case) - 70.1°C (case) 100°C (junction) |
| Thermal Design Power | 80 Watt |
