Feature
|
Technical Specifications
|
Processor
|
Up to two 3rd Generation Intel Xeon Scalable processors, with up to 40 cores per processor
|
Memory
|
- 32 DDR4 DIMM slots, supports RDIMM 2 TB max or LRDIMM 8 TB max, speeds up to 3200 MT/s
- Up to 16 Intel Persistent Memory 200 series (BPS) slots, 8 TB max
- Supports registered ECC DDR4 DIMMs only
|
Storage controllers
|
- Internal controllers: PERC H745, HBA355I, S150, H345, H755, H755N
- Boot Optimized Storage Subsystem (BOSS-S2): HW RAID 2 x M.2 SSDs 240 GB or 480 GB
- Boot Optimized Storage Subsystem (BOSS-S1) HW RAID 2 x M.2 SSDs 240 GB or 480 GB
- External PERC (RAID): PERC H840, HBA355E
|
Drive Bays
|
Front bays:
- Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB
- Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB
- Up to 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 245.76 TB
- Up to 24 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 368.84 TB Rear bays:
- Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 30.72 TB
- Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
|
Power Supplies
|
- 800 W Platinum AC/240 mixed mode
- 1100 W Titanium AC/240 mixed mode
- 1400 W Platinum AC/240 mixed mode
- 2400 W Platinum AC/240 mixed mode
|
Cooling Options
|
Air cooling, optional processor liquid cooling
|
Fans
|
- Standard fan/High performance SLVR fan/High performance GOLD fan
- Up to six hot plug fans
|
Dimensions
|
- Height – 86.8 mm (3.41 inches)
- Width – 482 mm (18.97 inches)
- Depth – 758.3 mm (29.85 inches) - without bezel
772.14 mm (30.39 inches) - with bezel
|
Form Factor
|
2U rack server
|
Embedded Management
|
- iDRAC9
- iDRAC Service Module
- iDRAC Direct
- Quick Sync 2 wireless module
|
Bezel
|
Optional LCD bezel or security bezel
|
OpenManage Software
|
- OpenManage Enterprise
- OpenManage Power Manager plugin
- OpenManage SupportAssist plugin
- OpenManage Update Manager plugin
|
Mobility
|
OpenManage Mobile
|
Integrations and Connections
|
OpenManage Integrations
- BMC Truesight
- Microsoft System Center
- Red Hat Ansible Modules
- VMware vCenter and vRealize Operations Manager
|
OpenManage Connections
- IBM Tivoli Netcool/OMNIbus
- IBM Tivoli Network Manager IP Edition
- Micro Focus Operations Manager
- Nagios Core
- Nagios XI
|
Security
|
- Cryptographically signed firmware
- Secure Boot
- Secure Erase
- Silicon Root of Trust
- System Lockdown (requires iDRAC9 Enterprise or Datacenter)
- TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ
|
Embedded NIC
|
2 x 1 GbE LOM
|
Network Options
|
1 x OCP 3.0 (x8 PCIe lanes)
|
GPU Options
|
Up to two double-width 300 W, or four single-width 150 W, or six single-width 75 W accelerators
|
Ports
|
Front Ports
- 1 x Dedicated iDRAC Direct micro-USB
- 1 x USB 2.0
- 1 x VGA
|
Rear Ports
- 1 x USB 2.0
- 1 x Serial (optional)
- 1 x USB 3.0
- 2 x RJ-45
- 1 x VGA (optional for liquid cooling configuration)
|
Internal Ports
|
PCIe
|
Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules
|
Operating System and Hypervisors
|
- Canonical Ubuntu Server LTS
- Citrix Hypervisor
- Microsoft Windows Server with Hyper-V
- Red Hat Enterprise Linux
- SUSE Linux Enterprise Server
- VMware ESXi
For specifications and interoperability details, see Dell.com
|
OEM-ready version available
|
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information, visit Dell.com
|
