Main Specifications

Host Interface

PCI Express 3.0 x16

Product Type

Workstation

Product Line

Quadro NVS

Memory Technology

DDR3

Memory Capacity

4 GB (2GB per GPU)

Max Displays

8 at 4,096 x 2,160 at 30Hz (4 at 4,096 x 2,160 at 60Hz)

Detailed Specifications

Processor

NVIDIA Quadro NVS 810

Memory Bandwidth

28.8 (GB/sec)

Memory Interface

128-bit (64-bit per GPU)

API Support

Graphics APIs: Shader Model 5.0, OpenGL 4.3, DirectX 11

Compute APIs: CUDA, DirectCompute, OpenCL

Graphics Resolution

Maximum DP 1.2 Resolution: 4096 x 2160 at 60Hz

Maximum DVI-D SL Resolution: 1920x1200 at 60Hz

Streaming Processor Cores

1,024 (512 per GPU)

NVIDIA CUDA™ Technology

Yes

HDCP Support

Yes

Mini DisplayPort Output

8

Mini-DP to DP Adapters

8 included

Max Graphics Card Power (W)

68W

Dual Slot

No

Dimensions

4.40” H x 7.80” L
